H.VIEW (16CH 4K/8MP/6MP/5MP/4MP/3MP/1080p/720p) Network Video Recorder, 16CH (16-Port PoE) NVR - Supports up to 16 x 4K IP POE Cameras, Supports up to 2x10TB Hard Drive (HDD is Not Included.)

H.VIEW (16CH 4K/8MP/6MP/5MP/4MP/3MP/1080p/720p) Network Video Recorder, 16CH (16-Port PoE) NVR - Supports up to 16 x 4K IP POE Cameras, Supports up to 2x10TB Hard Drive (HDD is Not Included.)

Save $20.00 Save $20.00
$299.99
$299.99 - $299.99
$299.99
$279.99
$279.99 - $279.99
$279.99
  • Description
  • Specs
  • Downloads

  • NVR FEATURES:

    • Supports 16-Channel 1080p/3MP/4MP/5MP/6MP/4K Resolution.

    • Records 16-Channels @ 1080p/3MP/4MP/5MP/6MP/4K.

    • Decoding Capacity: 2CH @ 4K / 30fps simultaneously or 16CH @D1 / 30fps.

    • Dual video outputs (HDMI and VGA) to connect multiple monitors

    • H.265 / H.264 video compression offers reduced file size and improved network performance for remote viewing

    • Remotely Access Using Standard Windows and Mac Browsers.

    • Easy to Install, Plug and Play: Plug and Manage All Cameras on Your Network.

    • Push notifications of motion events

    • Instant email alerts with snapshot attachment

    • Multiple Trigger/Alarm Events: Recording, PTZ, Tour, Video Push, Email, FTP, and Buzzer.

    • Supports up to 2 X 10TB Hard Drives (Hard Drive Not Included).

    • Guard Viewer apps for live viewing, playback, video recording.

    • Automatic firmware upgrade over the Internet ensures your system stays up-to-date

    • PC and Mac compatible - Guard station video management software gives you complete control over your security system from anywhere.

    [16CH 8MP Camera Input]: With 16ch recording, video and audio, playback and live view, resolution is up to 8MP/4K @ real time 30fps. Support 8mp, 6mp, 5mp, 4mp, 3mp and 2mp cameras to access. This H.265 POE NVR supports H.VIEW IP POE cameras and WIFI cameras, also supports the access of other Onvif IP cameras of other brands.

    [Intelligent Dual Network Segment]: The LAN of the recorder and the camera are separated from the network segment and the camera won’t occupy the bandwidth of the router network, and won’t be interfered by other network devices inside the router network, which makes the connection of the camera more stable. The video recorder intelligently distributes power according to the power consumption requirements of the camera, which supports a maximum of 120 meters of network cable transmission

    [PC Computer Remote Management]: Real-time video browsing, video playback, video download, monitoring point management, PTZ control, video storage management, alarm, patrol and other rich video monitoring business functions will all be realized through the computer Guard Station video management software. Multiple NVR recorders can be added and managed at the same time.

    [Remote Monitoring]: Supporting Android and iOS mobile phones and tablet PC to view images and sounds, it can control PTZ cameras, play back videos, take snapshots, receive alarm information, and support simultaneous remote monitoring of multiple devices.

    Plug & Play setup:Easy to configure, access and control. Scan QR Code on POE NVR from "Guard Viewer " app to instantly access live viewing and playback. Connects to and manages all the POE IP cameras on your network directly through their ethernet cables for ultimate ease and convenience in a home security system.



    Smart Motion Detection Alerts:When there are motion events, you'll receive instant app pushes & email alerts and the buzzer alarms of the NVR. Access the NVR to check the motion events and take actions at once to deter intruders before intrusion.

    Advanced H.265 compression technology lets you save on storage space which allows for longer recording times. H.265 technology compresses your video without sacrificing any of the UltraHD video quality. Intelligent search, playback, and backup functions provide enhanced ease of use and security (for example, motion detection event and exact search functions that are accurate to one second)

    Connection diagram



  • NVR Specifications

    Model NVR3216-16P
    Video/Audio Input
    IP Video Input 16-ch
    Network
    Incoming Bandwidth 112Mbps
    Outgoing Bandwidth 96Mbps
    Remote Users 128
    Protocols P2P, UPnP, NTP, DHCP, PPPoE
    Video/Audio Output
    HDMI/VGA Output HDMI:
    4k(3840x2160/30Hz),4k(3840x2160/60Hz),1024X768/60Hz,1280X720/60Hz,1280X1024/60Hz,1920X1080/50Hz,
    VGA:
    1920x1080p/60Hz, 1920x1080p/50Hz,1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
    Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
    Synchronous Playback 16-ch
    Corridor Mode Screen 3/4/5/7/9/10/12/16
    Decoding
    Decoding format Ultra 265/H.265/H.264
    Liveview/Playback 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
    Capability 1x8MP@30,1 x 6MP@30,1 x 5MP@30, 2 x 4MP@25, 2 x 3MP@30,4 x 1080p@25, 8 x 960p@25,8 x 720p@30
    Hard Disk
    SATA 2 SATA interface
    Capacity up to 10TB for each disk
    External Interface
    Network Interface 1 RJ45 10M/100M self-adaptive Ethernet Interface
    USB Interface Rear panel: 2 x USB2.0
    Supported Standard IEEE 802.3at, IEEE 802.3af
    External Interface
    Interface 8 RJ45 10M/100M self-adaptive Ethernet Interface
    Max Power Max 30W for single port
    Max 240W in total
    Supported Standard IEEE 802.3at, IEEE 802.3af
    General
    Power Supply 220V AC
    Power Consumption: ≤9 W (without HDD)
    Working Environment -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing)
    Dimensions (W×D×H) 260mm × 240mm × 46mm (10.2"×9.4"×1.8")
    Weight (without HDD) ≤2.4kg (5.29 lb)
